V1000
Fully modular cable design incorporates a single 1000W +12V output that delivers up to 83A.
80 PLUS Gold certified: up to 93% efficiency @ 50% load
Silent 135 mm FDB fan for lower noise and longer lifespan
Eight PCI-E 6+2 pin connectors to support high-end GPUs
100% high quality Japanese capacitor ensures performance and reliability.
Reliable 5 year warranty
- Modular Fully Modular
- Operating Temperature 0-40°C
- MB 20+4 Pin Connectors 1
- CPU 12V 4+4 Pin Connectors 2
- FDD Cable 4 Pin Connectors 1
- Category Above 750W
- Power Good Signal 100 - 500 ms
- MTBF >100,000 Hours
- Output Capacity 1000W
- 80 Plus Efficiency Gold
- Input Voltage 90-264Vac (Auto Range)
- Certification 80 Plus Gold
- PCI-e 6+2 Pin Connectors 8
- Input Frequency 60-50Hz
- SATA Connectors 9
- PFC Active PFC (>0.9 Typical)
- ATX Version Intel Form Factor ATX 12V V2.31
- Peripheral 4 Pin Connectors 4
- Fan Size Silent FDB 135mm
- Protections OVP
- Protections OPP
- Efficiency 90% Typically
- Protections SCP
- Protections UVP
- Series V Gold Series
- Protections OTP
- Dimensions (L x W x H) 150 x 170 x 86 mm / 5.9 x 6.7 x 3.4 inch
- Regulatory CCC
- Hold Up Time >17ms
- Regulatory CE
- Input Current 12-6A
- Regulatory FCC
- Regulatory BSMI
- Regulatory TUV
- Regulatory TUV-SUDNRTL
- Regulatory GOST
- Regulatory C-tick
- Regulatory KCC
- Model RS-A00-AFBA-G1
- Product Name V1000
