80 PLUS Certified Power Supply

MWE 550

High Efficiency and Low Noise

ErP 2013 Lot 6 Compliant

Proven Thermal Resistance

Quiet and Durable

Damage Resistant

Specifications

  • Operating Temperature 0-40°C
  • ErP 2013 Lot 6 Yes
  • MB 20+4 Pin Connectors 1
  • FDD Cable 4 Pin Connectors 1
  • Warranty 3 Years
  • Fan Speed 840-1980 RPM
  • CPU 12V 4+4 Pin Connectors 1
  • Power Good Signal 100 - 500 ms
  • MTBF >100,000 hours @ 25℃ ambient
  • Input Frequency 47-63Hz
  • Fan Size 120mm
  • Modular Non Modular
  • Fan Bearing HDB
  • PFC Active PFC (>0.9 Typical)
  • ATX Version Intel Form Factor ATX 12V V2.31
  • Efficiency 85% @ Typical Load
  • Input Current 4.5A
  • Hold Up Time >14ms
  • PCI-e 6+2 Pin Connectors 2
  • SATA Connectors 6
  • Peripheral 4 Pin Connectors 3
  • Protections OVP
  • Protections OPP
  • Series MWE White Series
  • Protections SCP
  • Dimensions (L x W x H) 140 x 150 x 86 mm
  • Protections OTP
  • Regulatory CCC
  • Input Voltage 200-240Vac
  • Model MPW-5502-ACABW
  • Regulatory CE
  • Regulatory RCM
  • Regulatory EAC
  • Product Name MWE 550
  • Regulatory TUV
