Designed for Storage Focused Builds
MasterCase MC500 High Storage Edition
MasterCase MC500 supports mammoth storage of up to ten HDDs and two SDDs, adjustable in position to allow for multiple system configurations...
Specifications
- Series MasterCase Series
- Materials Steel
- Radiator Support - Rear 120mm
- Power Supply Support Bottom Mount
- Dust Filters Top
- Dust Filters Front
- I/O Panel 2x USB 3.0
- Radiator Support - Rear 140mm
- Materials Plastic
- Size Mid Tower
- Pre-installed Fans - Front 2x 140mm, 1200RPM
- Power Supply Support ATX
- Dust Filters Bottom
- Fan Support - Rear 1x 120/140mm
- Radiator Support - Top 240mm
- Cable Routing 25-35mm
- I/O Panel 2x USB 2.0
- Motherboard Support ATX
- Expansion Slots 7
- Clearance - GFX 296mm (w/ 3.5" HDD cage)
- Motherboard Support Micro ATX
- Radiator Support - Top 120mm
- Motherboard Support Mini ITX
- Fan Support - Front 3x 120/140mm
- Color(s) Dark metallic grey exterior with black interior
- Fan Support - Top 2x 120mm
- Clearance - CPU Cooler 190mm
- Dimensions (L x W x H) 512 x 235 x 548 mm
- 2.5" / 3.5" Drive Bays (Combo) 10
- I/O Panel Audio In & Out (Supports HD Audio)
- Clearance - GFX 412mm (w/o 3.5" HDD cage)
- 2.5" Drive Bays 2 (Max. 4 SSD)
- Model Number MCM-M500-KNNN-S00
