MasterWatt Maker 1500 (no Bluetooth)
MasterWatt Maker 1500 (no Bluetooth) Full Modular Digital 80 PLUS Titanium Certified Power Supply
Specifications
- Category Above 750W
- 80 Plus Efficiency Titanium
- Modular Fully Modular
- Operation Voltage 100-240Vac
- ErP 2013 Lot 6 Yes
- MTBF 100,000 Hours
- MB 20+4 Pin Connectors 1
- CPU 12V 4+4 Pin Connectors 2
- PCI-e 6+2 Pin Connectors 12
- SATA Connectors 20
- FDD Cable 4 Pin Connectors 1
- Peripheral 4 Pin Connectors 12
- Input Frequency 47-63Hz
- Fan Bearing LDB
- Power Good Signal 100 - 500 ms
- Product Name MasterWatt Maker 1500 (no Bluetooth)
- Model MPZ-F001-AFBAT
- ATX Version ATX 12V v2.4
- PFC Active PFC (>0.95 Typical)
- Series MasterWatt Maker Series
- Legacy Power Supplies
- Fan Size 135mm
- Input Voltage 100-240Vac
- Protections OVP
- Protections OPP
- Protections SCP
- Efficiency 90-94%
- Hold Up Time 16ms
- Protections OTP
- Protections OCP
- Protections BOP
- Regulatory CCC
- Regulatory CE
- Dimensions (L x W x H) 200 x 150 x 86 mm
- Regulatory RCM
- Regulatory EAC
- Regulatory FCC
- Regulatory BSMI
- Regulatory KC
- Input Current 15-7.5A
- Regulatory TUV
