MasterWatt Maker 1200

Specifications

• Category Above 750W
• 80 Plus Efficiency Titanium
• Modular Fully Modular
• MTBF 100,000 Hours
• MB 20+4 Pin Connectors 1
• CPU 12V 4+4 Pin Connectors 2
• FDD Cable 4 Pin Connectors 1
• Power 1200 Watts
• PCI-e 6+2 Pin Connectors 10
• SATA Connectors 16
• Peripheral 4 Pin Connectors 12
• Power Good Signal 100 - 500 ms
• PFC Active PFC (>0.95 Typical)
• Input Frequency 47-63Hz
• Series MasterWatt Maker Series
• ATX Version ATX 12V, fully modular
• Legacy Power Supplies
• Product Name MasterWatt Maker 1200
• Fan Size 135mm Silencio FP Fan
• Input Voltage 100-240Vac
• Protections OVP
• Protections OPP
• Efficiency 90-94%
• Protections SCP
• Hold Up Time 16ms
• Protections OTP
• Protections OCP
• Regulatory CCC
• Regulatory CE
• Dimensions (L x W x H) 200 x 150 x 86 mm
• Input Current 12-6A
• Regulatory RCM
• Regulatory EAC
• Regulatory FCC
• Regulatory BSMI
• Regulatory KC
• Regulatory TUV
• Model MPZ-C001-AFBAT
