New Gen S Dual Chamber Pump

Expanded Radiator Surface

120mm Fan

Clean Classic Design

CryoFuze Performance Thermal Paste

model

Cooler Master has built upon the classic MasterLiquid L Series to present a redesigned and improved release of the MasterLiquid 120L Core. Featuring new design elements that bring a classic minimalist look to the series, the MasterLiquid 120L Core represents Cooler Master’s ongoing innovative spirit.

Gen S Dual Chamber Pump

Redesigned copper base targets heat spots with precision along with boosted water flow and pressure for enhanced cooling performance.

Expanded Radiator Surface

Expanded radiator fin surface accelerates heat dissipation for superior cooling.

120mm fan

An upgraded 120mm fan delivers optimal radiator performance.

Clean Classic Design

Clean minimalist design brings a refreshed modern facelift to the pump cover.

CryoFuze thermal PASTE

Includes premium CryoFuze thermal paste for exceptional heat conductivity.

Specifications

  • Product Number MLW-D12M-A17PK-R1
  • Exterior Color Black
  • CPU Socket Intel® LGA 1700 / 1200 / 1151 / 1150 / 1155 / 1156 socket
  • CPU Socket AMD® AM5 / AM4 / AM3+ / AM3 / AM2+ / AM2 / FM2+ / FM2 / FM1 socket
  • Radiator Material Aluminum
  • Radiator Dimensions 157 x 119.6 x 27.2 mm / 6.2 x 4.7 x 1.1 inch
  • Pump Dimensions 81 x 76 x 47 mm / 3.2 x 3 x 1.9 inch
  • Pump MTTF >70,000 Hours
  • Pump Noise Level 12 dBA (Max)
  • Pump Connector 3-Pin
  • Pump Rated Voltage 12 VDC
  • Pump Power Consumption 3.96W
  • Dimensions (L x W x H) 120 x 120 x 25 mm / 4.7 x 4.7 x 1.0 inch
  • Fan Quantity 1 PC
  • Fan Speed 650-1750 RPM ± 10%
  • Fan Airflow 71.93 CFM (Max)
  • Fan Noise Level 27.2 dBA (Max)
  • Fan Pressure 1.86 mmH₂O (Max)
  • Fan Bearing Type Rifle Bearing
  • Fan MTTF >160,000 Hours
  • Fan Power Connector 4-Pin (PWM)
  • Fan Rated Voltage 12 VDC
  • Fan Rated Current 0.26A
  • Fan Safety Current 0.37A
  • RAM Clearance N/A
  • Warranty 3 years
  • Series MasterLiquid Lite
  • Cooler Type Liquid Cooler
  • Radiator Size 120
