Square Is The New Cool

MasterFan SF240P ARGB

MasterFan SF240P ARGB, Our first 240mm square fan with addressable RGB lighting effect in Pro segment, provides a specific air cooling solution ideal

Specifications

  • Fan Rated Voltage 12 VDC
  • Fan Profiles Addressable RGB
  • RGB Rated Voltage 5 VDC
  • Legacy Cooling
  • RGB Connector 3-Pin ARGB
  • Warranty 2 years
  • Fan MTTF 160,000 Hours
  • Fan Bearing Type LDB
  • Fan Connector 4-Pin
  • Fan Noise Level 8 - 30 dBA
  • Number of LEDs 26pcs
  • RGB Rated Current 1.2A
  • Fan Safety Current 0.35A
  • Fan Power Consumption 3.84W
  • Fan Rated Current 0.32A
  • Fan Dimensions (L x W x H) 240 x 120 x 25 / 9.4 x 4.7 x 1 inch
  • Fan Weight 296g / 0.65lbs
  • Fan Speed 650-2400 RPM ± 10%
  • Fan Air Pressure 2.32 mmH2O ± 10%
  • Fan Airflow 43 x 2 CFM ± 10%
  • Product Number MFY-P2D2-24NPA-R1
