An upgraded driver IC boosts cooling performance while minimizing fan noise.
Bring On The Light
MasterFan MF120 Halo² White Edition
Following the popularity of the MasterFan 120 Halo series, Cooler Master has redesigned our Dual Loop LED series fan to introduce the new MasterFan MF120 Halo² White Edition . The fan blades have been increased by 10% over its predecessor to deliver better air flow and cooling performance. The frame has been designed with a hybrid frame structure to maintain stability without sacrificing fan operational real estate. The driver IC has been upgraded for increased cooling performance while minimizing fan noise. Cooler Master has maintained the elegant Dual Loop LED design featuring our Addressable Gen 2 RGB lighting to give you the most customizable lighting to fit our design needs.
Color
HYBRID FRAME DESIGN
A hybrid frame structure maintains stability without sacrificing fan blade size or performance.
UPGRADED DRIVER IC
An upgraded driver IC boosts cooling performance while minimizing fan noise.
Specifications
- Product Number MFL-B2DW-21NP2-R2
- Exterior Color White
- Dimensions (L x W x H) 120 x 120 x 25 mm / 4.7 x 4.7 x 1.0 inch
- Profile Addressable Gen 2 RGB
- Fan Speed 0-2050 RPM ± 5%
- Fan Airflow 51.88 CFM
- Fan Noise Level 27 dBA
- Fan Bearing Type Rifle Bearing
- Fan Pressure 2.89 mmH₂O
- Fan MTTF >160,000 Hours
- Fan Power Connector 4-Pin (PWM)
- Fan Rated Voltage 12 VDC
- Fan Rated Current 0.14A
- Fan Safety Current 0.37A
- Fan Power Consumption 1.68W
- RGB Connector 3-Pin ARGB
- RGB Rated Voltage 5 VDC
- RGB Rated Current 0.77A
- Fan Weight 174g / 0.38 lbs
- Warranty 2 years
- Cooler Type Case Fan
- Series MasterFan
- Fan Size 120
- LED Lighting ARGB
- Number of LEDs 24pcs
