HAF XB EVO
HAF XB EVO
- Materials Steel
- I/O Panel 2x USB 3.0
- Cooling Support - Top 1x 200mm Fan (Optional) - for Mesh Version (RC-902XB-KKN2) Only
- Legacy Cases
- Liquid Cooling Support - Rear 120mm Radiator x 1 (Optional)
- Cooling Support - Rear 1x 120mm Fan or 2x 80mm Fan (Optional)
- 5.25" Drive Bays 2
- 3.5" Drive Bays 4
- Liquid Cooling Support - Front 240mm radiator x 1 (optional) (Compatible with the Nepton 280L)
- Cooling Support - Front 2x 120mm XtraFlo Fan (Installed, 1200 RPM, 17 dBA), or 2x 140mm Fan (Optional)
- Motherboard Support ATX
- Expansion Slots 7
- Materials Polymer
- Motherboard Support Micro ATX
- Series HAF Series
- Motherboard Support Mini ITX
- Power Supply Support Standard ATX PS2 (The max. length of PSU: 180mm / 7.1 inch)
- Materials mesh front bezel
- Maximum Compatibility - CPU Cooler Height 180mm / 7.1 inch
- Maximum Compatibility - VGA Card Length 334mm / 13.1 inch
- Weight 8.2 kg / 18.1 lb
- I/O Panel Audio In & Out (Supports HD Audio)
- 2.5" Drive Bays 4 (converted from 3.5" drive bays)
- Dimensions (L x W x H) 442 x 330 x 423 mm / 17.4 x 13 x 16.7 inch
- Model Number RC-902XB-KWN2 (windowed version)
- Model Number RC-902XB-KKN2 (mesh version)
