G450M
G450M
- Operating Temperature 0-40°C
- MB 20+4 Pin Connectors 1
- FDD Cable 4 Pin Connectors 1
- Power Good Signal 100 - 500 ms
- MTBF >100,000 Hours
- Modular Semi Modular
- CPU 12V 4+4 Pin Connectors 1
- Category Under 500W
- 80 PLUS Rating 80 PLUS Bronze
- Legacy Power Supplies
- Input Frequency 60-50Hz
- Efficiency 85% Typically
- PFC Active PFC (>0.9 Typical)
- ATX Version Intel Form Factor ATX 12V V2.31
- PCI-e 6+2 Pin Connectors 2
- SATA Connectors 6
- Peripheral 4 Pin Connectors 3
- Protections OVP
- Protections OPP
- Input Voltage 100-240Vac (Full Range)
- Protections SCP
- Dimensions (L x W x H) 140 x 150 x 86 mm / 5.5 x 5.9 x 3.4 inch
- Protections UVP
- Output Capacity 450W
- Protections OTP
- Protections OCP
- Hold Up Time >16ms
- Input Current 8-4A
- Regulatory CCC
- Regulatory CE
- Regulatory RCM
- Regulatory EAC
- Regulatory FCC
- Regulatory BSMI
- Regulatory UL
- Regulatory TUV
- Model RS450-AMAAB1-xx
