CM 690 II Basic (Asia only)
CM 690 II Basic (Asia only)
- Cooling System - Bottom 2x 120mm Fan (Optional)
- Cooling System - HDD cage 120mm fan x 1 (optional)
- Color(s) Black
- Size Mid Tower
- Materials Plastic
- Cooling System - Right side 120/140 mm fan x 2 (optional)
- Cooling System - Left side 80 x 15mm fan x 1 (optional)
- Legacy Cases
- Cooling System - Rear 120mm red LED fan x 1, 1200RPM, 17dBA
- Cooling System - Top 120/140mm fan x 2 (optional)
- Power Supply Support ATX PS2
- Power Supply Support EPS 12V (Optional)
- I/O Panel 2x USB 2.0
- Expansion Slots 7+1
- Cooling System - Front 120 x 25mm blue LED fan x 1/ 1200RPM / 17dBA
- Materials Steel body
- 3.5" Drive Bays 6 (hidden)
- Materials Mesh bezel
- I/O Panel 1x Mic
- I/O Panel 1x eSATA
- I/O Panel 1x Audio (supports HD audio)
- 5.25" Drive Bays 4 (exposed, enclosed with two tool-free systems)
- Net Weight 8 kg / 17.64 lbs
- Dimensions (L x W x H) 214.5 x 496 x 528.8 mm / 8.4 x 19.5 x 20.8 inch
- Model Number RC-692B
