Name: B500 ver.2
SKU: b500-ver-2
Availability: InStock

Operating Temperature 0-40°C

MB 20+4 Pin Connectors 1

Certification 80 PLUS Standard

Floppy 1

CPU 12V 4+4 Pin Connectors 1

Category 500 to 750W

Power Good Signal 100 - 500 ms

MTBF >100,000 Hours

Input Frequency 47-63Hz

Modular Non Modular

Fan Size Silent 120mm HDB Fan

Legacy Power Supplies

PFC Active PFC (>0.9 Typical)

Hold Up Time >13ms

ATX Version Intel Form Factor ATX 12V V2.31

PCI-e 6+2 Pin Connectors 2

SATA Connectors 6

Peripheral 4 Pin Connectors 3

Protections OVP

Protections OPP

Protections SCP

Dimensions (L x W x H) 140 x 150 x 86 mm / 5.5 x 5.9 x 3.4 inch

Protections OTP

Protections OCP

Input Voltage 200-240Vac

Regulatory CE

Input Voltage 230V only

Efficiency >85% @ Typical Load

Regulatory EAC

Regulatory TUV

Input Current 5A@230Vac

Product Name B500 VER.2

Model RS-500-ACAB-B1

B500 ver.2
