Precision Cooling for Modern Performance

DT600 Series

• Larger Copper Base

• RAM Clearance Design

• AMD-Optimized Base Layout

• High Static-Pressure Fan

• Refined Modern Aesthetics

DT600 Series

The DT600 Series is designed to bring stronger cooling, cleaner aesthetics, and easier compatibility to modern systems. Its single-tower layout delivers efficient cooling in a compact footprint, while the fully coated finish gives the heatsink, heat pipes, and top cover a unified look that fits naturally into today’s high-performance builds.

Under the surface, the DT600 is engineered to solve real cooling challenges. An enlarged copper base increases contact area for more effective heat transfer, while the offset base layout is designed to better align with AMD processor hotspot locations. Paired with a high static-pressure fan, the DT600 helps push air through the heatsink more effectively, giving builders stronger cooling performance in a clean, compatible design.

LARGER COPPER BASE: MORE COVERAGE WHERE IT COUNTS


A larger copper base increases CPU contact area, giving the DT600 more surface coverage for faster heat transfer compared to standard six-heatpipe coolers.

DT600 SINGLE-TOWER 6-HEATPIPE COOLER VS. STANDARD 6-HEAT

PIPE COOLER:

HEAT DISSIPATION CAPACITY



RAM CLEARANCE DESIGN BUILT FOR CLEAN COMPATIBILITY


The compact single-tower structure is designed to avoid interference with RAM and motherboard VRM heatsinks, making the DT600 easier to install across a wide range of modern system configurations.

COMPACT SIZE: 162 MM TOWER HEIGHT


With an overall height of 162 mm, the DT600 offers strong compatibility with many mainstream PC cases while maintaining efficient single-tower cooling performance.

AMD-OPTIMIZED DESIGN: BETTER ALIGNMENT FOR AMD HOTSPOTS


The base is offset to match the unique CCD hotspot locations of AMD processors, helping improve heat transfer and cooling performance compared to traditional layouts.


HIGH STATIC-PRESSURE FAN: STRONGER AIRFLOW THROUGH THE FIN STACK


The newly developed fan provides higher static pressure than typical fans, helping push air through the heatsink more effectively for faster, more efficient cooling.

REDESIGNED MODERN AESTHETICS: CLEAN FINISH FOR A SHARPER BUILD


The DT600 features a fully coated finish that helps prevent oxidation on the heat pipes and fins. Paired with a newly designed top cover, it blends cleanly into the system and improves the overall visual appeal.

WIDE COMPATIBILITY SUPPORTS MAINSTREAM INTEL AND AMD PLATFORMS


The DT600 supports multiple mainstream Intel and AMD platforms, giving users a flexible cooling option for a wide range of modern PC configurations.

Specificaties

  • Product Number MAX-T6PN-220PK-C1 (Black); MAX-T6PN-220PW-CW (White)
  • CPU Compatibility Intel® LGA 1851 / 1700 / 1200 / 1151 / 1150 / 1155 / 1156; AMD® AM5 / AM4
  • Dimensions (L × W × H) 128 x 86 x 162 mm (5.04 x 3.39 x 6.38 in)
  • Material 6 heat pipes / aluminum fins / copper base
  • Fan Dimensions (L × W × H) 120 x 120 x 25 mm
  • Fan Lighting None
  • Fan Quantity (pcs.) 1
  • Fan Speed 2000 ± 10% RPM
  • Fan Airflow (max.) 114.2 m³/h (67.19 CFM)
  • Fan Pressure (max.) 2.31 mmH2O
  • Fan MTTF > 160,000 hours
  • Fan Noise Level (max.) 32.8 dBA
  • Fan Bearing Oil-impregnated sleeve bearing
  • Fan Power Connector 4-Pin PWM
  • Fan Rated Voltage 12 VDC
  • Fan Rated Current 0.13 A
  • Fan Safety Current 0.37 A
  • Fan Power Consumption 1.56 W
  • Package 8pcs/Carton
  • Warranty 3 years
